An efficiently formed foundation
Tekst Roel van GilsBeeld AA Schroefpalen

AA Schroefpalen from Nijmegen has literally laid the foundations for the striking Manhattan Urban Residence in Roermond.
The foundation was built in a relatively short time, using a large number of grout-injected screw piles formed in the ground. And all of this was achieved without vibration, with no disruption to the surrounding area. We spoke to Remko Peters, Marketing Manager at AA Schroefpalen, about the benefits of this foundation method.

AA Schroefpalen was brought in to lay the foundations, having worked with Jongen Bouwpartners for many years. “With more than 25 years of experience, we have all the expertise needed to produce screw piles installed without vibration,” says Peters. “A key advantage of this technique is that we can deliver much faster and more flexibly than other foundation systems. We can complete an entire foundation in a short time for homes, commercial buildings and apartment buildings, as we have here for Manhattan Urban Residence.”

Considerate to the surrounding area
AA Schroefpalen forms the grouted screw piles on site. “Using our mobile drilling rigs, we drill a ‘hole’ to the required depth and diameter,” Peters explains. “Once we reach the bottom, a valve opens, we slowly withdraw the drill and concrete is pumped in, followed by the reinforcing bars. This foundation method produces virtually no noise or nuisance from vibration. It is much more considerate to the surrounding area than, for example, installing driven piles. This means foundations can be installed without any problems close to, or even right next to, existing buildings. We form the grouted screw piles on site in a range of diameters and lengths, up to 24 metres. We use a range of machines, including mobile drilling rigs (weighing approximately 45 to 68 tonnes), concrete pumps (with a capacity of 150 cubic metres per hour) and midi excavators.”

Trust
According to Peters, another advantage of using grouted screw piles is that changes can still be made to the design at the last minute. “The piles are formed in the ground, so a different diameter or greater depth is not usually a problem.” That does not mean, however, that installing grouted screw piles requires no coordination. “For example, we must be able to rely 100% on our ready-mixed concrete suppliers. We therefore work with regular partners, so we can always deliver within the agreed timeframe. We pump a considerable amount of ready-mixed concrete into the ground. Concrete mixers are constantly coming and going. A pile, for example, 12 metres deep and 40 centimetres in diameter, will easily contain around 5 m³ of ready-mixed concrete.”
Speed, lead time, price and minimal disruption were important reasons for Jongen Bouwpartners to choose AA Schroefpalen’s grouted screw piles for the Manhattan foundation, Peters says. “Thanks to good coordination and preparation by our client, the project went smoothly for everyone.”
