Precast concrete

An artistic concrete design

An artistic concrete design

Facades shaped by nature

Naturalis Museum is undergoing a major expansion. To accommodate the growing number of visitors, nine new exhibition halls, workshop spaces, a restaurant and a shop are being added. Outside, the striking building references nature in many different ways. The facades of the public hall, for example, display an intriguing pattern formed from three-dimensional concrete elements.

‘We relish the opportunity to work on these unique, prestigious facades.’ (Photo courtesy of Lievense)

Hibex - Voor deze unieke, prestigieuze gevels lopen we warm' Lievense kopiëren

At over 40 m high, the glass crown facade is the new Naturalis’s eye-catching feature. The facade, comprising no fewer than 341 concrete elements, was designed by Neutelings Riedijk Architecten. The design was translated into precast concrete elements in collaboration with JP van Eesteren and Hibex. Hibex specialises in architectural concrete. Marc Spanjer, project manager at Hibex, says: “We do everything except standard grey concrete.” Concrete also fits with Naturalis’s sustainability ambitions. The museum opts for materials that age naturally.

The pattern of the white bands was designed by a fashion designer.

Hibex - Het patroon van de witte stroken werd ontworpen door een modeontwerpster kopiëren

The glass crown facade was built using a hybrid construction. A load-bearing steel structure was chosen as the base, with the concrete facade elements fixed to it. Hibex used a mix of white cement and Norwegian marble to give the elements their white colour. The elements were then grit-blasted, revealing the sparkle of the marble beneath the surface. After the concrete elements had been manufactured, the contractor fitted them with the frames and glazing, allowing the completed elements to be delivered to site ready for installation.

Bands in white relief concrete

Untreated element, fresh out of the mould.

Hibex - Onbewerkt element, vers uit de mal kopiëren

For the design of the white bands in the red natural stone section of the facade, the client consulted artists. How could the reddish-brown natural stone bands be interspersed in an attractive way? This search led Naturalis to a designer who developed a design based on natural forms, captured in black-and-white photographs. Using specialist software, ABT converted this into a depth pattern that Hibex could use to control the milling machines for the various moulds. The pattern continues across the elements. In total, thirteen patterns were needed to produce all the different configurations.

Challenges

“It was a real Hibex job,” says Spanjer. “Developing and making the elements required an intensive engineering process. Together with Lievense, formerly Bartels, we converted the elements into concrete shapes suitable for production. The moulds required were no less challenging. We developed them in collaboration with Modelmakerij Noord Nederland. By pooling our expertise, we achieved a design that was both flexible and dimensionally accurate. In the end, we were able to produce all the elements using a limited number of moulds. And with good results: all the crown facade elements fitted.” Naturalis is scheduled to reopen around mid-2019.

Text | Liliane Verwoolde   Images | Hibex
