Artists in wood bring concrete dreams to life

Artists in wood bring concrete dreams to life

Verhoeven Timmerfabriek makes wooden concrete formwork for construction and infrastructure projects. Large concrete plants and contractors, in the Netherlands and internationally, have been turning to the timber specialist from Venray for more than forty years, and for good reason: the results are stunning and the possibilities sometimes exceed the bounds of the imagination.

In Venray, Verhoeven Timmerfabriek’s large workshop is where the team works every day to create the perfect formwork. Michiel Hendriks, manager of concrete formwork: “Most of the time it’s for a precast concrete plant, sometimes it’s for an in-situ project, such as a bridge. But ultimately, it’s all about shape.”

Thinking inside out

Verhoeven uses different methods depending on the project. “For simpler projects, we work from 2D drawings, which we convert into a negative wooden mould by ‘thinking inside out’. For more complex projects, we use 3D drawings to build the formwork. Spatial awareness is essential for this work, and we train our employees in it. You have to keep in mind at all times that the concrete element must come out of the formwork cleanly after curing, without being damaged.”

The finished result above the A12.

Let your imagination run wild

The expertise the joinery has built up over the years has greatly expanded the possibilities for creating beautiful fair-faced concrete. Verhoeven: “Our biggest formwork project ever was the Verlengde Waalbrug near Nijmegen, in 2015. It’s a double-curved bridge for which we made 12,000 square metres of formwork in our workshop, using 250 wooden elements. It’s unique to design something like that in fair-faced concrete. That’s our message too: don’t be too quick to say it can’t be done, let your imagination run wild first. Then we’ll work out together how to make it happen.”

A seamless finish

A more recent project is the Boekelosebrug in Hengelo, for which Verhoeven supplied the formwork for the two abutments. The identical abutments are 35 metres long and six metres high, with a double-curved shape. The formwork consisted of forty elements. After the first abutment was poured, everything was dismantled and reassembled on the opposite side. Hendriks: “None of the separate elements leaves a seam, and the finished surface is perfectly smooth. That takes a lot of manual work: sanding, filling, sanding again and applying a finish. That’s how you get smooth concrete and clean release from the formwork.”

Formwork for Lansingerland station.

Lansingerland

“We took a different approach to the cladding on the new Lansingerland station. The station spans the A12 and features a finely detailed concrete panel as its edge finish, with open and closed shapes resembling a branching structure. Instead of making the mould with its reverse form from timber, we machined it from thick sheets of plywood using a five-axis milling machine. These were also extensively sanded and carefully finished until the result was perfect. CUR-Aanbeveling 100 is regarded as the benchmark in the world of fair-faced concrete. For us, it’s
the minimum standard.”

Heidelberg

“It doesn’t matter whether it’s a beautiful balcony or a major piece of art for Rijkswaterstaat, as long as it’s challenging,” Hendriks stresses. “We love creating unique projects, and that’s where we excel. We recently made the moulds for the concrete façade elements of Heidelberg Cement’s new head office in Germany. They’re truly unique and detailed with exceptional precision. It’s a prestigious project that suits us perfectly.”

Forty skilled craftspeople work at Verhoeven Timmerfabriek. “Three have been here for 45 years, and two recently came back after retiring. That says something about the working atmosphere and how rewarding this trade is. And there’s always another great project coming in. As a recognised training company, we also train our own people, with three apprentices in training at any one time. Our craftspeople learn 99% of what they can do on the job.”
